| Sym. |
Per Unit |
Description |
Part No. |
| 1 |
1 |
Suction Piece No. 4779 |
160-04-2012-08 |
| 2 |
1 |
Suction Piece O-ring |
160-47-0271-07 |
| 3 |
1 |
Suction Piece Wear Ring - NO LONGER AVALABLE |
160-08-2383-13 |
| 4 |
4 |
Wear Ring Self-Tapping Screws |
160-14-1447-60 |
| 5 |
10 |
Suction Piece Washers |
160-14-0740-41 |
| 6 |
10 |
Suction Piece Cap Screws |
160-14-0731-00 |
| 7 |
1 |
Suction Piece Pipe Plug |
160-31-0061-66 |
| 8 |
1 |
Bearing Housing No. 3982 |
160-08-2047-11 |
| 9 |
1 |
Bearing Housing O-ring |
160-47-0232-05 |
| 10 |
2 |
Bearing Housing Lip Seals |
160-10-1274-13 |
| 11 |
1 |
Lip Seal Back Up Plate |
160-10-1342-03 |
| 12 |
1 |
Bearing Grease Fitting |
160-23-0562-03 |
| 13 |
1 |
Bearing Cap Lip Seal |
160-10-1264-07 |
| 14 |
1 |
Bearing Cap No. 4365 |
160-08-2205-27 |
| 15 |
4 |
Bearing Housing Cap Screws |
160-14-1303-30 |
| 16 |
4 |
Bearing Cap Screws |
160-14-0731-00 |
| 17 |
1 |
Bearing Cap Pipe Plug |
160-31-0058-46 |
| 18 |
1 |
Inspection Cap No. 4761 |
160-51-0104-03 |
| 19 |
1 |
Inspection Cap O-Ring |
160-47-0258-04 |
| 20 |
1 |
Inspection Cap Lock Wrench |
160-22-1810-02 |
| 21 |
2 |
Wrench Nylatch Assembly |
160-23-1418-07 |
| 22 |
2 |
Swivel Block |
160-51-0201-05 |
| 23 |
2 |
Swivel Block Pin |
160-14-0802-04 |
| 25 |
2 |
Hold Down Cap Screw |
160-14-0734-07 |
| 26 |
1 |
Splined Impeller Shaft |
160-07-5271-04 |
| 27 |
1 |
Thrust Bearing |
160-08-2202-04 |
| 28 |
1 |
Bearing Retaining Ring |
160-14-0767-07 |
| 29 |
1 |
Impeller 9-9/16" Dia. "A" Cut (Alum.) NO LONGER AVALABLE |
160-05-2528-04 |
| 29.1 |
1 |
Impeller 9-3/8" Dia. "B" Cut (Alum.) |
160-05-2529-03 |
| 29.2 |
1 |
Impeller 9-1/4" Dia. "C" Cut (Alum.) NO LONGER AVAILABLE |
160-05-2530-00 |
| 29.3 |
1 |
Impeller 9-1/8" Dia. "O" Cut (Alum.) NO LONGER AVAILABLE |
160-05-2531-09 |
| 29.4 |
1 |
Impeller 9" Dia. "B" Cut (Alum.) NO LONGER AVAILABLE |
160-05-2532-08 |
| 30 |
1 |
Impeller Key |
160-14-0614-02 |
| 31 |
1 |
Impeller Nut |
160-14-0606-02 |
| 32 |
2 |
Impeller Nut Set Screws |
160-14-0717-08 |
| 33 |
1 |
Bowl Bearing Sand Cap |
160-08-2044-06 |
| 34 |
2 |
Bowl Bearing Sand Cap Set Screw |
160-14-0724-09 |
| 35 |
1 |
Bowl No. 4417 |
160-04-1548-03 |
| 36 |
1 |
Bowl to Steering Housing O-ring |
160-47-0256-06 |
| 37 |
1 |
Bowl Grease Fitting w/Cap |
160-23-0562-03 |
| 38 |
1 |
Bowl Bearing No. 3980 |
160-08-2043-15 |
| 39 |
1 |
Bowl Bearing O-ring |
160-47-0032-07 |
| 40 |
1 |
Hi-Flow Nozzle Plug Assembly |
160-50-0056-02 |
| 41 |
8 |
Bowl Cap Screws |
160-14-0731-00 |
| 43 |
1 |
Contour Grill Housing No. 4920 |
160-51-0175-07 |
| 43.1 |
1 |
Flat Grill Housing No. 4418 |
160-51-0171-19 |
| 43.2 |
1 |
Vee Grill Housing No. 4418 |
160-51-0175-07 |
| 44 |
1 |
Suction Piece Bottom Gasket |
160-13-0854-72 |
| 45 |
14 |
Grill Housing Nut |
160-14-0726-07 |
| 46 |
14 |
Grill Housing Washer |
160-14-0756-00 |
| 47 |
14 |
Grill Housing Machine Screws |
160-14-1713-00 |
| 48 |
1 |
Grill Insert Standard No. 4419 |
160-51-0102-05 |
| 48.1 |
1 |
Grill Insert Contour No. 5523 |
160-51-0273-08 |
| 49 |
2 |
Grill Insert Lock Washers |
160-14-0745-04 |
| 50 |
2 |
Grill Insert Cap Screws |
160-14-0743-06 |
| 51 |
1 |
Transom Adapter No. 4889 9° to 18° |
160-52-0262-00 |
| 51.1 |
1 |
Transom Adapter No. 4331 2° to 9° |
160-52-0262-00 |
| 52 |
1 |
Cable Gland Assembly 1/2" NPT |
160-23-1408-09 |
| 53 |
1 |
Transom Adapter O-ring |
160-47-0451-09 |
| 54 |
1 |
Transom Adapter Drain Plug |
160-31-0061-66 |
| 55 |
2 |
Transom Adapter Wood Screws |
160-23-0572-01 |
| 56 |
10 |
Transom Adapter Cap Screw |
160-14-1713-00 |
| 57 |
10 |
Transom Adapter Washer |
160-14-0756-00 |
| 58 |
10 |
Transom Adapter Nut |
160-14-0726-07 |
| 59 |
1 |
Steering Housing No. 4766 |
160-52-0248-09 |
| 60 |
4 |
Steering Housing Cap Screws |
160-14-0731-00 |
| 61 |
4 |
Steering Housing Washers |
160-14-0740-41 |
| 62 |
1 |
Tiller Arm No. 4764 |
160-52-0249-24 |
| 63 |
1 |
Tiller Arm Groove Pin |
160-14-1573-09 |
| 64 |
1 |
Deflector Top Pivot Pin |
160-52-0238-01 |
| 65 |
1 |
Top Pivot Pin O-ring |
160-47-0114-08 |
| 66 |
2 |
Deflector Pivot Bearing |
160-08-2196-02 |
| 67 |
1 |
Pivot Pin Retaining Rings |
160-14-1918-03 |
| 68 |
1 |
Deflector Bottom Pivot Pin |
160-52-0359-04 |
| 69 |
12 |
Spacer Washers for Pivot Pins |
160-52-0078-04 |
| 82 |
1 |
Deflector No. 4414 |
160-52-0241-06 |
| 83 |
1 |
Top Pivot Pin Groove Pin |
160-14-0804-02 |
| 84 |
1 |
Groove Pin Spring Pin |
160-14-1521-02 |
| 85 |
1 |
Cable Pivot Pin |
160-52-0239-00 |
| 86 |
2 |
Cable Pivot Pin Bearings |
160-08-2195-11 |
| 87 |
2 |
Cable Pivot Pin Retainer |
160-14-0775-07 |
| 88 |
1 |
Reverse Gate No. 4415 |
160-52-0242-05 |
| 89 |
2 |
Reverse Gate Pivot Pin |
160-52-0237-02 |
| 90 |
2 |
Reverse Gate Pivot Bearings |
160-08-2196-02 |
| 91 |
4 |
Pivot Pin Retaining Rings |
160-14-0774-08 |
| 92 |
1 |
Shift Cable Pivot Bracket No. 4751 |
160-52-0244-03 |
| 93 |
2 |
Cable Pivot Bracket Set Screws |
160-14-0052-19 |
| 94 |
1 |
Cable Pivot Bracket O-ring |
160-47-0008-07 |
| 95 |
1 |
Cable Lock Nut |
160-14-0797-01 |
| 96 |
2 |
Cable Pivot Bracket Bearings |
160-08-2195-11 |
| 97 |
1 |
Cable Pivot Bracket Retainer |
160-14-0775-07 |
| 98 |
1 |
Steering Tube Kit for Rideguide, Morse & Teleflex |
160-51-0431-07 |
| 98.1 |
1 |
Steering Tube Bushing Only |
160-23-0568-07 |
| 103 |
1 |
Engine Bracket (Chevy. Olds & 460 Ford) |
160-51-0236-04 |
| 103.1 |
1 |
Eng Bracket (Ford & Chrysler) |
160-51-0251-04 |
| 104 |
2 |
Rubber Engine Mount |
160-23-0557-00 |
| 105 |
2 |
Spacer Sleeve |
160-22-1105-06 |
| 106 |
8 |
Washer |
160-9911-2716 |
| 107 |
2 |
Stainless Lock Washer |
160-14-0722-01 |
| 108 |
2 |
Stainless Hex Cap |
160-14-1303-30 |
| 109 |
1 |
Rockwell Shaft Assy. |
See 12Y Section |
| 110 |
opt |
Salety Tilt Rudder |
160-52-0233-06 |
| 111 |
opt |
Rudder Sheer Pin (Pkg. of 5) |
160-52-0259-05 |
